NOM-030-ENER-2016 is an Official Mexican Standard that establishes energy efficiency specifications, test methods, and labeling requirements for light-emitting diode (LED) lamps intended for general lighting in residential, commercial, and public settings in Mexico. Issued by the Secretaría de Energía (Secretary of Energy) with support from the Secretaría de Economía (Secretary of Economy), it was published in the Official Gazette of the Federation (Diario Oficial de la Federación) on December 2, 2016, and became effective on June 2, 2017, replacing NOM-030-ENER-2012. The standard aims to promote energy savings, ensure product performance, and provide consumers with clear information to encourage the adoption of efficient lighting technologies.

Scope and Applicability:

NOM-030-ENER-2016 applies to LED lamps used for general illumination, including:

  • Integrated LED lamps (with built-in drivers) for household, commercial, or public use.
  • Omnidirectional and directional lamps (e.g., A-type bulbs, spotlights, PAR lamps).
  • Lamps with common bases (e.g., E26, E27, GU10) operating on Mexico’s electrical grid (e.g., 127 V AC, 60 Hz).

Exclusions:

  • LED lamps for specialized applications (e.g., automotive, medical, or signaling).
  • LED luminaires (fixed fixtures, covered by NOM-031-ENER).
  • Non-integrated LED lamps requiring external drivers.
  • Colored or decorative lamps not intended for general lighting.

NOM-030-ENER-2016

The standard covers new LED lamps sold, manufactured, or imported in Mexico, focusing on energy efficiency, safety, and performance.

Key Requirements:

1. Energy Efficiency Specifications:

  • • Minimum Luminous Efficacy: Lamps must achieve a minimum light output per watt (lumens/W), typically ≥80 lm/W for omnidirectional lamps and ≥70 lm/W for directional lamps, ensuring efficient energy use.
  • • Power Factor: Requires a minimum power factor (e.g., ≥0.7 for lamps >5 W) to reduce electrical grid strain.
  • • Standby Power : Limits power consumption in standby mode (if applicable) to minimize losses.

2. Performance Requirements:

  • Color Rendering Index (CRI): Must be ≥80 to ensure accurate color representation.
  • Correlated Color Temperature (CCT): Must fall within specified ranges (e.g., 2700K–6500K) for consistent lighting quality.
  • Lumen Maintenance: Lamps must retain ≥70% of initial lumens after a defined test period (e.g., 6,000 hours), ensuring durability.
  • Harmonic Distortion: Total harmonic distortion (THD) must be ≤40% to prevent electrical interference.

3. Test Methods :

  • Based on Mexican standards (e.g., NMX-J series) and harmonized with international protocols like IES LM-79 (photometric testing) and LM-80 (lumen maintenance).
  • Tests measure:
  • Luminous flux (lumens).
  • Power consumption (watts).
  • CRI, CCT, and power factor.
  • Endurance and switching cycles (e.g., 15,000 on/off cycles).
  • Conducted under controlled conditions (e.g., 25°C, 127 V AC, 60 Hz).

4. Labeling

5. Compliance

  • Manufacturers or importers must obtain a Certificate of Conformity from accredited certification bodies through testing by approved laboratories.

Purpose and Enforcement:

NOM-030-ENER-2016 drives the transition to energy-efficient LED lighting, reducing electricity demand and greenhouse gas emissions in Mexico, where lighting accounts for
a significant portion of energy use. It ensures LED lamps meet performance and safety standards, replacing less efficient technologies like incandescent or fluorescent bulbs.

Enforcement is managed by:

  • Comisión Nacional para el Uso Eficiente de la Energía (CONUEE).
  • PROFECO (Federal Consumer Protection Agency) for market surveillance.
  • Customs authorities for import verification.

Non-compliance—such as failing efficacy tests or mislabeling—can result in fines, product seizures, or sales bans.
